No.

Item

General Parameter

Remark

1

Rated Capacity

Typical

600mAh

Standard discharge(0.2C5A) after Standard charge

Minimum

580mAh

2

Nominal Voltage

3.2V

Mean Operation Voltage

3

Voltage at end of

Discharge

2.0V

Discharge Cut-off Voltage

4

Charging Voltage

3.65V

5

Internal Impedance

≤80mΩ

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after shipment and cycles less than 5 times

6

Standard charge

Constant Current 0.2C5A

Constant Voltage 3.65V

0.01 C5A cut-off

7

Standard discharge

Constant current 0.2C5A

end voltage2.0V

No.

Item

Criteria

Test Conditions

1

Cycle Life

Higher than  70 % of the Initial Capacities of the Cells

Carry out  1000 cycle

C harging / Discharging in the below condition.

1.Charge:   Standard Charge, per 3.3.1

2.Discharge:  0.2  C 5 A to  2.0 V

3. Rest Time between charge/discharge:30min.

4.Temperature:20±5°C

2

Leakage-Proof

No leakage

(visual inspection)

After full charge  with standard charge , store at 60±3°C ,  60±10%RH for 1
